0802 Perf Bind Cvr Sht Posit: With Feed
Adjust the horizontal alignment of the cover sheet position when performing perfect binding.
When you bind the copies with the perfect binder, make this adjustment if the center of the book block's
spine and the center of the cover sheet are misaligned horizontally.
Press [ ] or [ ] to move the image feed direction or reverse feed direction.
Paper feed direction
Spine of the book
Front
cover
CWY010
Setting Items
Default
Value
Max.
Value
Min.
Value
Step Unit
Set 0.0 5.0 -5.0 0.1 mm
0803 Perfect Binding Finishing Angle
Square the top, bottom, and outside edges when trimming a deck of paper.
Make this adjustment if the three edges of the deck of paper cut by the perfect binder are not square.
Enter the distance from the square part at each edge.
Fore Edge
Tail Edge Head Edge
DWP570
7. Adjustment Settings for Operators
338
