Booklet Unit Transport, Entrance

Fold Unit Entrance Sensor

Preparation

• Booklet unit (page 29)

• Booklet stapler (page 28)

1. Remove sensor bracket [A] (

x1).

2. Remove sensor [B] ( x1, x5)

Booklet Side-to-Side Jogging

Booklet Stapler Side Fence Motor

The booklet stapler side fence motor is on the back of the booklet unit.

1. Replacement and Adjustment
