Symbols, Abbreviations and Trademarks
Conventions
Symbol What it means
Binding screw (shoulder hexagonal head)
Binding screw (round flathead)
Black screw (heavy, fusing unit, TCRU)
Bushing
C-ring
Clip
Connector
E-ring
FFC (Flat Film Connector)
FFC (Flat Film Connector)
FFC (Flat Film Connector)
Gear
Harness clamp
Harness clamp: metal: fusing unit
Hook (or tab release: sensors)
Knob screw (black)
Knob screw (sliver)
Pivot screw
Screw: most common: silver
Shoulder screw
