Horizontal Paper Feed
Entrance
Entrance Roller Motor(
Preparation
Rear upper cover (page 15)
Rear lower cover (page 16)
Right panels (page 24)
1. The entrance roller motor is under the paper entrance guide.
2. A tension spring is attached to the motor bracket behind the main control board. The main control
board mounting bracket must be removed in order to remove and re-attach this spring.
Horizontal Paper Feed
45
