Shift Tray Full Sensors 1, 2, 3, 4 (500)
The tray full sensors are all mounted on the same vertical stay at the left rear corner of the finisher:
• Shift Tray Full Sensor (500)
• Shift Tray Full Sensor (1000)
• Shift Tray Full Sensor (1500)
• Shift Tray Full Sensor (2500)
Preparation
• Rear upper cover (page 15)
• Rear lower cover (page 16)
1. Remove the vertical stay cover ( x3).
Shift Tray
85
