Switches
Front Door Switch
Preparation
• Open the front door.
• Upper inner cover (page 19)
1. Locate the door switch [A] on the front.
2. Inside the finisher, disconnect switch [B] (
x4).
3. Pinch both sides of the switch and push it out.
1. Replacement and Adjustment
166
