Emergency Shift Tray Stop Switch

Preparation

• Shift tray jogger unit (page 74)

• Left upper cover (page 23)

1. The switch [A] is on the front end of the left upper cover.

2. Turn the cover over.

3. Remove the switch [A] ( x2, x1).

Switches

167
