3. Remove PCB [A] ( x5, x2).
PSU
Preparation
• Switch the system off.
• Disconnect the finisher from its power source.
• Wait at least 30 minutes.
• Right panels (page 24)
• The PSU will retain residual charge, even after the machine has been turned off.
• Allow at least 30 minutes for any residual charge to dissipate before you touch the PSU.
1. The PSU is on the right, bottom edge of the unit.
1. Replacement and Adjustment
162

Ricoh SR5050 Specifications

General

Type	Finisher
Stapling Capacity	50 sheets
Punching	Optional
Paper Size	A3 to A5
Paper Weight	52 - 300 g/m²
Staple Positions	Top, Bottom, 2 staples
Function	Stapling
Compatibility	Compatible with various Ricoh MFPs
