RIGOL Chapter 6 MATH and Measurement
6-28 MSO1000Z/DS1000Z User’s Guide
All Measurement
All measurement could measure all the time and voltage parameters (each
measurement source has 28 items) of the current measurement source and display
the results on the screen. Press Measure  Measure All to enable or disable the
all measurement function. Press All Measure Source and use to select the
channel(s) to be measured (CH1-CH4 and MATH).
 When all measurement is enabled, “One-key” measurement is also valid.
 “To Clear the Measurement” will not clear the results of all measurement.
Figure 6-6 All Measurement
One-key Measurement
All Measurement
