Chapter 1 Quick Start RIGOL
MSO1000Z/DS1000Z User’s Guide 1-25
To Use the Built-in Help System
The help system of this oscilloscope provides instructions for all the function keys
(including the menu keys) at the front panel. Press Help to open the help interface
and press again to close the interface. The help interface mainly consists of two parts.
The left are “Help Options”. The right is the “Help Display Area”.
Figure 1-15 Help Interface
You can press the button (except the power key
, the multifunction knob and
the menu page up/down key
/ ) directly at the front panel to get the
corresponding help information in the “Help Display Area”.
Help Options Help Display Area
To Next Page
