RIGOL Chapter 16 Remote Control
16-6 MSO1000Z/DS1000Z User’s Guide
Remote Control via LAN
1. Connect the device
Connect the oscilloscope to your LAN using a network cable.
2. Configure network parameters
Configure the network parameters of the oscilloscope according to the
description in “LAN Configuration”.
3. Search for device resource
Start the Ultra Sigma, click
and the window as shown below is
displayed. Click “Search” to search for the instrument resource connected to the
local network.
The name of the instrument resource found will be displayed in the window at
the right side, as shown in the figure below. Click “OK” to add the instrument
resource.
4. View device resource
The resources found will appear under the “RIGOL Online Resource” directory as
shown in the figure below.
To Next Page
