RIGOL Chapter 14 Store and Recall
14-2 MSO1000Z/DS1000Z User’s Guide
Storage System
Press Storage to enter the store and recall setting interface.
The internal memory (Local Disk) of this oscilloscope is 90.5 MByte. It provides a USB
Host interface at the front panel to connect USB storage device for external storage.
The USB storage device connected is marked as “Disk D”.
Storage Type
Press Storage Storage to select the desired storage type. The default is
“Picture”. The storage and recall descriptions of each type are as follows.
1. Picture
Save the screen image to external memory in “.png”, “.bmp8”, “.bmp24”, “.jpeg”
or “.tiff” format. You can specify the file name and saving directory and save the
corresponding parameter file (*.txt) under the same directory using the same
file name. This parameter file is the same as the “Parameters
” function. The
recall of image and parameter files is not supported.
After selecting this type:
Press PicType to select the desired storage format.
Press Param to enable or disable the parameter save function.
Press Invert to enable or disable the invert function.
Press Color to select the desired storage color. It can be set to “Gray” or “Color”.
After a USB storage device is connected, press at the front panel to
quickly save the current screen image under the root directory of the USB
2. Traces
Save the waveform data to external memory in “*.trc” format. The data of all the
channels turned on can be saved in the same file. At recall, the data will be
displayed on the screen directly.
3. Waves
Save the waveform data to external memory in “*.wfm” format. The stored files
contain the waveform data of the four analog channels and the main setting
information of the oscilloscope and all the data can be recalled.
To Next Page
