Chapter 19 Appendix RIGOL
MSO1000Z/DS1000Z User’s Guide 19-1
Chapter 19 Appendix
Appendix A: Accessories and Options
Description
Order Number
Model
DS1104Z (100MHz, 4-analog channel)
DS1104Z
DS1104Z-S (100MHz, 4-analog channel + 2-channel
25MHz signal source)
DS1104Z-S
DS1074Z (70MHz, 4-analog channel)
DS1074Z
DS1074Z-S (70MHz, 4-analog channel + 2-channel 25MHz
signal source)
DS1074Z-S
MSO1104Z (100 MHz, 4-analog channel+16-digital
channel)
MSO1104Z
MSO1104Z-S (100 MHz, 4-analog channel+16-digital
channel +2-channel 25MHz signal source)
MSO1104Z-S
MSO1074Z (70 MHz, 4-analog channel+16-digital
channel)
MSO1074Z
MSO1074Z-S (70 MHz, 4-analog channel+16-digital
channel +2-channel 25MHz signal source)
MSO1074Z-S
DS1054Z (50 MHz, 4-analog channel)
DS1054Z
Standard
Accessories
Power Cord conforming to the standard of the country
-
USB Cable
CB-USBA-USBB-
FF-150
4 Passive Probes (150 MHz)
RP2200
1 Logic Analyzer Pobe (only MSO1000Z/MSO1000Z-S)
RPL1116
Quick Guide
-
Resource CD (include User’s Guide and application
software)
-
Optional
Accessories
Rack Mount Kit
RM-DS1000Z
Memory
Depth
Options
24Mpts (single channel)/ 12Mpts (dual-channel)/ 6 Mpts
(four-channel)
MEM-DS1000Z
Waveform
Record
Options
This option provides the waveform record and playback
function.
REC-DS1000Z
Advanced
Trigger
Options
RS232/UART trigger, I2C trigger, SPI trigger, Runt trigger,
Window trigger, Nth edge trigger, delay trigger, timeout
trigger, Setup/Hold trigger
AT-DS1000Z
Serial
Protocol
Analysis
Options
RS232/UART decoding kit
I2C decoding kit
SPI decoding kit
SA-DS1000Z
Note: All the options or accessories can be ordered from you local RIGOL Office.
