Chapter 13 Signal Source RIGOL
MSO1000Z/DS1000Z User’s Guide 13-15
5. Time
Press Time to set the duration of the current point. This setting is limited by the
times of the previous point and following point. The time of point 1 is fixed at 0 s.
For the setting method, please refer to the introduction in “
Parameter Setting
Method”.
6. Insert
Press Insert to insert a new waveform point in the middle position between the
current point and the next point.
7. Delete
Press Delete to delete the current point from the waveform and connect the
remaining points using the current interpolation mode.
Note: Point 1 cannot be deleted.
8. Apply
Press Apply to finish editing the current waveform.
9. Save
Press Save to enter the file store interface. Please refer to the introduction in
“
Store and Recall” to save the current waveform file in “.arb” format in the
internal memory or external memory (you can overwrite the original file or save
the current waveform again).You can select the arbitrary waveforms in the
internal or external memory for output. For the details, refer to the introduction
in “To Select Waveform”.
Modulation
The built-in signal generator of MSO1000Z/DS1000Z series oscilloscope supports
amplitude modulation (AM) and frequency modulation (FM). The modulated
waveform consists of the carrier waveform and modulating waveform. The carrier
waveform is the waveform output from the signal generator and the modulating
signal can be the built-in sine, square, ramp waveform or noise signal.
Press Src1Mod to open the source 1 modulation setting menu. Press Modulation
to turn on or off the modulation function. Press Mod.Type to set the modulation
type of the current signal to “AM” or “FM”. Then, you can set the modulation
parameters according to the selected modulation type.
