RIGOL Chapter 14 Store and Recall
14-4 MSO1000Z/DS1000Z User’s Guide
Internal Storage and Recall
“Setups” and “Param” (internal recall is not supported) in Storage support internal
storage. In the following part, the storage and recall method and procedures of
internal storage are introduced.
1. Save the specified oscilloscope setting in internal memory.
1) Connect a signal to the oscilloscope and obtain stable display.
2) Press Storage  Storage to select “Setups” or “Param”and press Save
and use to select “Local Disk” (blue shading) and press down to
open the local disk.
3) Press New File and use the pop-up keyboard to create a new file name.
For the details, please refer to the introduction in “
To Create a New File
or Folder”. If this type of file is saved in the internal memory, use
to
select this file and then Save and Delete are illuminated. At this point,
pressing down Save will execute the storage operation and the original file
will be overwritten; pressing Delete will delete the original file. Use to
select
and then press down to return to the previous directory.
2. Load the specified type of file in internal memory.
1) Press Storage  Storage to select “Setups” and then press Load and use
to select “Local Disk” and then press down to open the local disk.
2) If this type file is saved in the internal memory, use
to select the desired
file and press Load to load the file selected.
