Chapter 7 Digital Channel RIGOL
MSO1000Z/DS1000Z User’s Guide 7-3
Note:
― When you have turned off channels D7-D0 at the same time using D7-D0,
you can still turn on or off any of the channels via the channel selection
menu. When you have turned on channels D7-D0 at the same time using
D7-D0, the channels in the list switch to ON status automatically. The
situation of channels D15-D8 is similar.
― Only user-defined digital channel groups can be selected.
For how to define channel groups, please refer to the introduction in “Group
Set”.
Group Set
Press Group Set to enter the user-defined group setting menu. You can perform
group and ungroup operations on the 16 digital channels.
Group:
The group operations of Group1-Group4 are the same and Group1 is taken as an
example for illustration.
Press Group1 to turn on channels D0-D15 selection list (the status label is
located at the left side of each channel), rotate
to select the channel to be
added into Group1 and press down or Group1 to add the channel selected
to Group1. Channels added into Group1 are marked with
and channels that
are not added into Group1 is marked with
.
Use the same method to group the other channels. Each channel can only be
added into a single group and channels that are already added into other group
cannot be selected (its status label
is gray). You can group the 16 digital
channels (D0-D15) via the group setting.
Ungroup:
Press UnGroup to open the channel/group list and rotate to select the
desired channel/group. If any of channels D0-D15 is selected, pressing down
will cancel the group operation of the channel; if any of Group1-Group4 is
selected, pressing down
will cancel the group operations of all the channels
in the group.
Note:
― You can only perform the ungroup operation on the grouped digital
channels or digital channel groups.
― If none group is set, UnGroup will be grayed out and disabled.
