108 Rockwell Automation Publication 2080-UM002N-EN-E - November 2022
Chapter 6 Micro870 Controller Distributed Network Protocol
Event Reporting This section covers how to generate DNP3 events from DNP3 Data Objects and how to report
the generated events by polled response or unsolicited response.
Generate Events
The controller has a separate buffer area that you can use to log DNP3 events internally.
The maximum number of the Events that can be logged is 10000 (see DNP3 10K Event Logging
on page 110), regardless of the Event data type. In 2080-L70E-24QxBN controllers, a Data-Set
event can consume multiple numbers of the event buffers.
If the number of the generated events reaches this value, the controller sets IIN2.3
[EVENT_BUFFER_OVERFLOW]. Further events are not logged until the logged events are
reported to DNP3 Master and the buffer is available.
The logged events are not removed until they are reported to DNP3 Master successfully.
Logged event can also be cleared when one of the following events occur:
• New OS firmware upgrade
• New user program download.
Figure 6
shows how to generate events for a Binary Input Object and a 16-bit Analog Input
Object. In the DNP3 Slave configuration, Binary Input Object Data and 16-bit Analog Input Object
Data is configured in the DNP3 mapping table.
250 Read Only VSTR
length of the string
value
Device manufacturer's product name and model
Supported ranges:
2080-L70E-24xxxN SER A where xxx is QWB or QBB.
For example, 2080-L70E-QWBN SER A or 2080-L70E-
24QBBN SER A.
251 — — — Reserved for future assignment —
252 Read Only VSTR 19 Device manufacturer's name
This variation returns the Company name, Rockwell
Automation.
253 Read Only — — Reserved for future assignment —
254 Read Only — — Non-specific all attributes request
This variable returns all of the variations in this group
except this variation.
255 Read Only — — List of attribute variations
This variation returns the R/W property for each
variation.
0 for Read Only
1 for Read or Write
Object Group 0, Variations for Attribute Set 0 (Continued)
Variation Read/Write
Attribute
Data Type
Max Length in Bytes Description Value
