Rockwell Automation Publication 2080-UM002N-EN-E - November 2022 69
Chapter 6
Micro870 Controller Distributed Network
Protocol
Overview This chapter describes how to configure the DNP3 communication settings. Topics include:
Channel Configuration for
DNP3 Slave
The default communication protocol for the serial ports is DF1 Full-Duplex. To communicate
with Distributed Network Protocol (DNP3), the channel must be configured for DNP3 Slave.
The default communication protocol for the Ethernet channel in the controller is EtherNet/IP.
To communicate with DNP3 over IP protocol, select DNP3 over IP Enable in the Ethernet
configuration page.
To program the controller, use Connected Components Workbench software version 20.01.00
or later.
Topic Page
Channel Configuration for DNP3 Slave 69
DNP3 Slave Application Layer 92
DNP3 Objects and Controller Variables 96
DNP3 Device Attribute Object 106
Event Reporting 108
Collision Avoidance 112
Time Synchronization 113
Diagnostics 114
Function Codes 116
Implementation Table 117
IMPORTANT The DNP3 protocol is only supported in the following Micro870
controllers.
• 2080-L70E-24QBBN
• 2080-L70E-24QWBN
