Roland Sound Canvas SC-8850 User Manual

217
Appendices
Parameter Setting Value Value (Hex.) MSB/LSB (H)
09 : Rotary 01 22
Low Slow 0.05–0.35–10.0 *6 03
Low Fast 0.05–6.40–10.0 *6 04
Low Accl 0–3–15 *14 05
Low Level 0–127 00–7F 06
Hi Slow 0.05–0.90–10.0 *6 07
Hi Fast 0.05–7.50–10.0 *6 08
Hi Accl 0–11–15 *14 09
Hi Level 0–64–127 00–7F 0A
Separate 0–96–127 00–7F 0B
+ Speed Slow/Fast 00/7F 0D
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
# Level 0–127 00–7F 16
10 : Stereo Flanger 01 23
Pre Filter Off/LPF/HPF 00/01/02 03
Cutoff 250–8k *9 04
Pre Dly 0–1.6ms–100ms *1 05
+ Rate 0.05–0.60–10.0 *6 06
Depth 0–24–127 00–7F 07
# Feedback -98%–+80%–+98% 0F–71 08
Phase 0–180 00–5A 09
Balance D> 0E–D=E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–104–127 00–7F 16
11 : Step Flanger 01 24
Pre Dly 0–1.0ms–100ms *1 03
Rate 0.05–0.30–10.0 *6 04
Depth 0–95–127 00–7F 05
+ Feedback -98%–+30%–+98% 0F–71 06
Phase 0–180 00–5A 07
# Step Rate 0.05–2.75–10.0 *6 08
Balance D> 0E–D=E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–96–127 00–7F 16
12 : Tremolo 01 25
Mod Wave Tri/Sqr/Sin/Saw1/Saw2 00/01/02/03/04 03
+ Mod Rate 0.05–3.05–10.0 *6 04
# Mod Depth 0–96–127 00–7F 05
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–127 00–7F 16
13 : Auto Pan 01 26
Mod Wave Tri/Sqr/Sin/Saw1/Saw2 00/01/02/03/04 03
+ Mod Rate 0.05–3.05–10.0 *6 04
# Mod Depth 0–96–127 00–7F 05
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–127 00–7F 16
❍ Effects that affect the level (compressor type)
14 : Compressor 01 30
Attack 0–72–127 00–7F 03
Sustain 0–100–127 00–7F 04
Post Gain 0/+6/+12/+18 00/01/02/03 05
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
+ Pan L63–0–R63 00–7F 15
# Level 0–104–127 00–7F 16
Parameter Setting Value Value (Hex.) MSB/LSB (H)
15 : Limiter 01 31
Threshold 0–85–127 00–7F 03
Ratio 1/1.5,1/2,1/4,1/100 00/01/02/03 04
Release 0–16–127 00–7F 05
Post Gain 0/+6/+12/+18 00/01/02/03 06
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
+ Pan L63–0–R63 00–7F 15
# Level 0–127 00–7F 16
❍ Effects that broaden the sound (chorus type)
16 : Hexa Chorus 01 40
Pre Dly 0–2.4ms–100ms *1 03
+ Rate 0.05–0.45–10.0 *6 04
Depth 0–127 00–7F 05
Pre Dly Dev 0–5–20 00–14 06
Depth Dev -20–+2–+20 2C–54 07
Pan Dev 0–16–20 00–14 08
# Balance D> 0E–D=E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–112–127 00–7F 16
17 : Tremolo Chorus 01 41
Pre Dly 0–1.6ms–100ms *1 03
Cho Rate 0.05–0.45–10.0 *6 04
Cho Depth 0–40–127 00–7F 05
Trem Phase 0–80–180 00–5A 06
+ Trem Rate 0.05–3.05–10.0 *6 07
Trem Sep 0–96–127 00–7F 08
# Balance D> 0E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–127 00–7F 16
18 : Stereo Chorus 01 42
Pre Filter Off/LPF/HPF 00/01/02 03
Cutoff 250–8k *9 04
Pre Dly 0–1.0ms–100ms *1 05
+ Rate 0.05–0.45–10.0 *6 06
Depth 0–111–127 00–7F 07
Phase 0–180 00–5A 09
# Balance D> 0E–D=E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–104–127 00–7F 16
19 : Space D 01 43
Pre Dly 0–3.2ms–100ms *1 03
+ Rate 0.05–0.45–10.0 *6 04
Depth 0–127 00–7F 05
Phase 0–180 00–5A 06
# Balance D> 0E–D=E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–96–127 00–7F 16
20 : 3D Chorus 01 44
Pre Dly 0–1.0ms–100ms *1 03
+ Cho Rate 0.05–0.45–10.0 *6 04
Cho Depth 0–72–127 00–7F 05
Out Speaker/Phones 00/01 11
# Balance D> 0E–D=E–D 0<E 00–7F 12
Low Gain -12–0–+12 34–4C 13
Hi Gain -12–0–+12 34–4C 14
Level 0–80–127 00–7F 16
