Roland Sound Canvas SC-8850 User Manual

224
Appendices
Effect Parameter Value Conversion Table
Here is a table for converting between the hexadecimal value and the actual setting for each parameter. These parameters are used
in the following effect types.
1. Pre Delay Time 2. Delay Time1 6. Rate1 56: Cho/Delay 26: Reverb 11. LPF
10: Stereo Flanger 23: 3 Tap Delay 07: Phaser 57: FL/Delay 28: 3D Delay 34: Lo-Fi 2
11: Step Flanger 24: 4 Tap Delay 08: Auto Wah 58: Cho/Flanger 37: OD → Delay 54: Rhodes Multi
16: Hexa Chorus 09: Rotary 60: OD/Rotary 40: DS → Delay
17: Tremolo Chorus 3. Delay Time2 10: Stereo Flanger 61: OD/Phaser 43: EH → Delay 12. Manual
18: Stereo Chorus 25: Tm Ctrl Delay 11: Step Flanger 62: OD/Auto Wah 44: Cho → Delay 07: Phaser
19: Space-D 12: Tremolo 63: PH/Rotary 45: FL → Delay 54: Rhodes Multi
20: 3D Chorus 4. Delay Time3 13: Auto Pan 64: PH/Auto Wah 51: Clean Gt Multi 1 55: Keyboard Multi
26: Reverb 21: Stereo Delay 16: Hexa Chorus 56: Cho/Delay 61: OD/Phaser
27: Gate Reverb 22: Mod Delay 17: Tremolo Chorus 7. Rate 2 57: FL/Delay 63: PH/Rotary
29: 2 Pitch Shifter 28: 3D Delay 18: Stereo Chorus 48: GTR Multi 1 64: PH/Auto Wah
30: Fb P.Shifter 37: OD → Delay 19: Space-D 49: GTR Multi 2 9. Cutoff Freq
35: OD → Chorus 40: DS → Delay 20: 3D Chorus 50: GTR Multi 3 10: Stereo Flanger 13. Azimuth
36: OD → Flanger 43: EH → Delay 22: Mod Delay 51: Clean Gt Multi 1 18: Stereo Chorus 31: 3D Auto
38: DS → Chorus 44: Cho → Delay 31: 3D Auto 52: Clean Gt Multi 2 34: Lo-Fi 2 32: 3D Locate
39: DS → Flanger 45: FL → Delay 35: OD → Chorus 53: Bass Multi
41: EH → Chorus 56: Cho/Delay 36: OD → Flanger 54: Rhodes Multi 10. EQ Freq 14. Accl
42: EH → Flanger 57: FL/Delay 38: DS → Chorus 55: Keyboard Multi 01: Stereo-EQ 04: Humanizer
44: Cho → Delay 39: DS → Flanger 47: Rotary Multi 09: Rotary
45: FL → Delay 5. Delay Time4 41: EH → Chorus 8. HF Damp 49: GTR Multi 2 60: OD/Rotary
46: Cho → Flanger 48: GTR Multi 1 42: EH → Flanger 21: Stereo Delay 51: Clean Gt Multi 1 63: PH/Rotary
54: Rhodes Multi 50: GTR Multi 3 44: Cho → Delay 22: Mod Delay 52: Clean Gt Multi 2
56: Cho/Delay 51: Clean Gt Multi 1 45: FL → Delay 23: 3 Tap Delay 53: Bass Multi
57: FL/Delay 52: Clean Gt Multi 2 46: Cho → Flanger 24: 4 Tap Delay 55: Keyboard Multi
58: Cho/Flanger 55: Keyboard Multi 47: Rotary Multi 25: Tm Ctrl Delay
1 234567891011 12 13 14
Pre Delay Delay Delay Delay Delay HF Cutoff EQ
Value Value Time Time 1 Time 2 Time 3 Time 4 Rate1 Rate2 Damp Freq Freq LPF Manual Azimuth Accl
(Hex.) (Dec.) (ms) (ms) (ms) (ms) (ms) (Hz) (Hz) (Hz) (Hz) (Hz) (Hz) (Hz) (deg)
00 0 0.0 200 200 0.0 0 0.05 0.05 315 250 200 250 100 L180(=R180) 0
01 1 0.1 205 205 0.1 5 0.10 0.10 “ “ “ “ 110 “ “
02 2 0.2 210 210 0.2 10 0.15 0.15 “ “ “ “ 120 “ “
03 3 0.3 215 215 0.3 15 0.20 0.20 “ “ “ “ 130 “ “
04 4 0.4 220 220 0.4 20 0.25 0.25 “ “ “ “ 140 “ “
05 5 0.5 225 225 0.5 25 0.30 0.30 “ “ “ “ 150 “ “
06 6 0.6 230 230 0.6 30 0.35 0.35 “ “ “ “ 160 L168 “
07 7 0.7 235 235 0.7 35 0.40 0.40 “ “ “ “ 170 “ “
08 8 0.8 240 240 0.8 40 0.45 0.45 400 315 250 315 180 “ 1
09 9 0.9 245 245 0.9 45 0.50 0.50 “ “ “ “ 190 “ “
0A 10 1.0 250 250 1.0 50 0.55 0.55 “ “ “ “ 200 L156 “
0B 11 1.1 255 255 1.1 55 0.60 0.60 “ “ “ “ 210 “ “
0C 12 1.2 260 260 1.2 60 0.65 0.65 “ “ “ “ 220 “ “
0D 13 1.3 265 265 1.3 65 0.70 0.70 “ “ “ “ 230 “ “
0E 14 1.4 270 270 1.4 70 0.75 0.75 “ “ “ “ 240 L144 “
0F 15 1.5 275 275 1.5 75 0.80 0.80 “ “ “ “ 250 “ “
10 16 1.6 280 280 1.6 80 0.85 0.85 500 400 315 400 260 “ 2
11 17 1.7 285 285 1.7 85 0.90 0.90 “ “ “ “ 270 “ “
12 18 1.8 290 290 1.8 90 0.95 0.95 “ “ “ “ 280 L132 “
13 19 1.9 295 295 1.9 95 1.00 1.00 “ “ “ “ 290 “ “
14 20 2.0 300 300 2.0 100 1.05 1.05 “ “ “ “ 300 “ “
15 21 2.1 305 305 2.1 105 1.10 1.10 “ “ “ “ 320 “ “
16 22 2.2 310 310 2.2 110 1.15 1.15 “ “ “ “ 340 L120 “
17 23 2.3 315 315 2.3 115 1.20 1.20 “ “ “ “ 360 “ “
18 24 2.4 320 320 2.4 120 1.25 1.25 630 500 400 500 380 “ 3
19 25 2.5 325 325 2.5 125 1.30 1.30 “ “ “ “ 400 “ “
1A 26 2.6 330 330 2.6 130 1.35 1.35 “ “ “ “ 420 L108 “
1B 27 2.7 335 335 2.7 135 1.40 1.40 “ “ “ “ 440 “ “
1C 28 2.8 340 340 2.8 140 1.45 1.45 “ “ “ “ 460 “ “
1D 29 2.9 345 345 2.9 145 1.50 1.50 “ “ “ “ 480 “ “
1E 30 3.0 350 350 3.0 150 1.55 1.55 “ “ “ “ 500 L96 “
1F 31 3.1 355 355 3.1 155 1.60 1.60 “ “ “ “ 520 “ “
20 32 3.2 360 360 3.2 160 1.65 1.65 800 630 500 630 540 “ 4
21 33 3.3 365 365 3.3 165 1.70 1.70 “ “ “ “ 560 “ “
22 34 3.4 370 370 3.4 170 1.75 1.75 “ “ “ “ 580 L84 “
23 35 3.5 375 375 3.5 175 1.80 1.80 “ “ “ “ 600 “ “
24 36 3.6 380 380 3.6 180 1.85 1.85 “ “ “ “ 620 “ “
25 37 3.7 385 385 3.7 185 1.90 1.90 “ “ “ “ 640 “ “
26 38 3.8 390 390 3.8 190 1.95 1.95 “ “ “ “ 660 L72 “
27 39 3.9 395 395 3.9 195 2.00 2.00 “ “ “ “ 680 “ “
28 40 4.0 400 400 4.0 200 2.05 2.05 1000 800 630 800 700 “ 5
29 41 4.1 405 405 4.1 205 2.10 2.10 “ “ “ “ 720 “ “
2A 42 4.2 410 410 4.2 210 2.15 2.15 “ “ “ “ 740 L60 “
2B 43 4.3 415 415 4.3 215 2.20 2.20 “ “ “ “ 760 “ “
2C 44 4.4 420 420 4.4 220 2.25 2.25 “ “ “ “ 780 “ “
2D 45 4.5 425 425 4.5 225 2.30 2.30 “ “ “ “ 800 “ “
2E 46 4.6 430 430 4.6 230 2.35 2.35 “ “ “ “ 820 L48 “
2F 47 4.7 435 435 4.7 235 2.40 2.40 “ “ “ “ 840 “ “
