72
Creating a Sound or Drum Set
Using Chorus and Delay
For Drum Instruments, you cannot use both chorus and delay simultaneously. If in
the drum edit screen either the Chorus Send or Delay Send parameters are marked
by an asterisk (*), that parameter is not valid. However if you modify the value of
that parameter, the parameter will be enabled. In other words, either chorus or delay
will be valid, whichever was set last.
fig.6-17
Assign Group
Each Instrument can be given a number, and instruments with the identical number
are treated as an Assign group. No two instruments of the same Assign group will
sound together. If while one instrument is sounding, a MIDI message is received to
play another instrument in the same Assign group, the first instrument will be
turned off first. This is a useful way to prevent two instruments from sounding si-
multaneously that would not normally do so. For example, since it is obviously im-
possible for a hi-hat to simultaneously produce both an open hi-hat sound and a
closed hi-hat sound, these two sounds could be set to the same Assign group (the
same number) so that they would not sound together.
Numbers from Non, 1 to 127 can be selected, but instruments for which Non is se-
lected will not be turned off by other instruments. In other words, instruments with
a setting of Non will not be treated as an Assign group.
Switching drum sets in the drum screen
Even when you are in the drum screen, you can still switch drum sets, etc.
■ Selecting Drum Maps
Use the PART [ ] [ ] buttons to select the Drum map.
At the factory settings, you can select A1, B1, C1, and D1.
A1: Drum1 of Part Group A
A2:
Drum2 of Part Group A (Only when a Drum Part is added by Part Mode set-
tings)
B1: Drum1 of Part Group B
B2:
Drum2 of Part Group B (Only when a Drum Part is added by Part Mode settings)
C1: Drum1 of Part Group C
C2:
Drum2 of Part Group C (Only when a Drum Part is added by Part Mode settings)
D1: Drum1 of Part Group D
D2:
Drum2 of Part Group D (Only when a Drum Part is added by Part Mode set-
tings)
Be aware that if you select a
different Drum Set, the
parameter values will be
initialized.
For details about Drum1,
Drum2 and Part Mode,
refer to p.37, 55.
