11—Input and Track Channel Tools
Roland VS-2480 Owner’s Manual www.rolandus.com 167
The CH EDIT ASSIGN Screen
On a track channel’s ASSIGN screen, you can route input channel, FX return, Aux bus
and Direct bus signals, or other tracks, to the current channel’s track for recording. The
screen acts like the EZ ROUTING VIEW screen (Page 292), but without virtual “wires.
To route an input channel’s signal or another track to the current channel’s track:
use the cursor buttons to select the desired signal source and turn the TIME VALUE
dial clockwise—the selected signal source highlights to show that it’s routed to the
current channel’s track. To disconnect the source, turn the TIME/VALUE dial
counter-clockwise.
click the desired signal source with your mouse—the selected signal source
highlights to show that it’s routed to the current channel’s track. To disconnect the
source, click it again.
Parameter View
The CH EDIT PRM.V (for “Parameter View”) feature allows you to view a selected CH
EDIT parameter in multiple channels at the same time. You can also adjust the
parameter in any of the displayed channels. This can save you time when you need to
adjust the same parameter in a group of channels.
You can route as many input channel signals or tracks to the current channel’s track as
you like.
If you select a stereo source—linked input channels, tracks or Aux busses—both linked
signals will be combined and routed into the current channel’s track. If the current
channel’s linked to another channel, the left side of the source signal will go to the odd-
numbered track and the right side to the even-numbered track.
To activate the Parameter View, press F6 (PRM.V) from any CH EDIT screen. On a track
channel’s CH EDIT VIEW screen, however, F6 (PRM.V) is unavailable when the
STATUS parameter is selected—choose another parameter to activate F6 (PRM.V).
The 24 input
channels
Tracks
The eight
Direct Busses
The eight
Aux Busses
The eight
FX returns
Selected channel and
parameter (group)
Parameter
Parameter
