17—Working with FX Channels
234 www.rolandus.com Roland VS-2480 Owner’s Manual
Adding Effects to a Headphone Mix
When you’ve created a headphone mix using an Aux bus, it’s easy to add an effect to
any of its signals. Send each channel’s signal to the effect as desired. The following
steps describe how to route the effect to the Aux bus:
1. Press TR-17-24•FX RTN to select the group of channels that includes the eight FX
returns channels.
2. Press the CH EDIT button for the FX return channel belonging to the effect you want to
send to the headphone mix. The FX return channel CH EDIT parameters appear.
3. Set the Send Status parameter for the Aux bus you’re using to its available Pre or Post
value, depending on the Aux bus’s configuration (Page 207).
4. Set the amount of the effect to be sent to the headphone mix.
For the effect to sound its best, use a linked pair of Aux busses for a stereo headphone
feed. In Steps 4 and 5 above, you’ll be setting up both linked Aux busses
simultaneously—use the linked Aux busses’ balance control to position the stereo
effect as desired in the mix.
You can also set the send level using the PAN/AUX SEND 1-8 knobs—see “Activating
Knob or Fader Control of Aux Send Levels” on Page 141.
Aux 1’s
Send Status
parameter
