4—Setting Up and Basic Operations
64 www.rolandus.com Roland VS-2480 Owner’s Manual
Configuring the VS-2480
Setting Up the VGA Monitor, Mouse and Keyboard
You’ll want to make sure your mouse, keyboard and VGA monitor are properly set up.
All of the settings for these devices are found on the same UTILITY menu pages. To get
there:
1. Press UTILITY.
2. Press PAGE—if necessary—until “SYSTEM” appears above F1.
3. Press F1 (SYSTEM).
4. Press F2 (Param2).
5. Use the
,
,
and
buttons as necessary to select each setting—a setting’s
outline darkens when it’s selected—and turn the TIME/VALUE dial to choose the
desired value.
If you don’t have a VGA monitor or keyboard, skip over its parameters.
VGA Monitor Parameters
Mouse Parameters
ASCII Keyboard Parameters
Parameter: What it sets: Typical setting is:
VGA OUT Turns the VGA output on or off On
REFRESH RATE Sets the rate at which the monitor re-
draws it image
Manufacturer’s
recommended setting
H. POSITION Shifts the image left or right 0
V. POSITION Shifts the image up or down 0
Consult your VGA monitor’s documentation to learn its recommended refresh rate. If
you select a value the monitor doesn’t support, image quality may be poor, and damage
to the monitor may result.
The VGA parameters are described in greater detail on Page 361.
Parameter: What it sets: Typical setting is:
PS/2 MOUSE Turns the mouse on or off On
POINTER SPEED Sets how fast the mouse’s cursor
moves
3
Parameter: What it sets: Typical setting is:
PS/2 KEYBOARD Turns the keyboard on or off On
KEYBOARD TYPE Selects the nationality of the ASCII
keyboard you’re using
101/104 (in USA);
106/109 (Japan)
VS2480OMUS.book 64 ページ ２００６年２月７日 火曜日 午後４時１６分
