Sanyo PLC XU115 - XGA LCD Projector User Manual

10
 Kensington Security Slot
Thisslotisfora Kensingtonlockusedtodeter
theftoftheprojector.
 * KensingtonisaregisteredtrademarkofACCOBrands
Corporation.
Bottom
Back
① Infrared Remote Receiver
② WIRELESS Indicator
③ Focus Ring
④ Projection Lens
⑤ Zoom Lever
⑥ Lens Cap
⑦ Top Controls and Indicators
⑧ Air Intake Vent
⑨ Exhaust vent
⑩ Speaker
⑪ Air Intake Vent (back and bottom)
⑫ Terminals and Connectors
⑬ Power Cord Connector
⑭ SD Card Slot
⑮ LAN Connection Terminal
⑯ Lamp Cover
⑰ Filters
⑱ Adjustable Feet
⑯
⑮⑭⑬⑪
CAUTION
Hot air is exhausted from the exhaust
vents. Do not put heat-sensitive objects
nearthisside.

Part Names and Functions
⑫
⑰
⑨
⑩
⑪

Note:
② WIRELESS Indicator and ⑮ LAN
Connection Terminal are for the
Network function. Refer to the
owner’s manual “Network Set-up and
Operation”.
⑭ SD Card Slot is for the Memory
Viewer function. Refer to the owner's
manual "Memory Viewer fuction".
CAUTION
Do not turn on a projector with lens cap
attached. High temperature from light
beammaydamagelenscapandresultin
firehazard.
Front
⑱
⑥③ ④ ⑤① ⑦ ⑧②
⑧
