Installation
Connecting to Video Equipment
Cables used for connection
•VideoandAudioCable(RCAx3)
•S-VIDEOCable
•AudioCable
(Cablesarenotsuppliedwiththeprojector.)
ExternalAudioEquipment
Unplug the power cords of
both the projector and external
equipment from the AC outlet
beforeconnectingcables.

Notes:
• WhentheAUDIOOUTisplugged-in,theprojector'sbuilt-
inspeakerisnotavailable.
 •The S-VIDEO jack connection overrides the VIDEO
jackconnectionwhenselectingAUTOintheInputMenu
(p.40).
SD
KB3AC
AUDIO OUT
(stereo)
S-videocable
Videoandaudiocable
VIDEO
S-VIDEOAUDIOIN
CompositeVideoandAudioOutput
S-videoOutput
(R)(L)(Video)
Audiocable
(stereo)
AudioInput
