㉖ NETWORK button
Select the Network input or Memory viewer input.  See
 the owner's manual of
"NetworkSet-upandOperation".
To ensure safe operation, please
observethefollowingprecautions:
–Donotbend,drop,orexposetheremote
controltomoistureorheat.
–For cleaning, use a soft dry cloth. Do
notapplybenzene,thinner,splay,orany
chemicalmaterial.
Remote Control
①
Part Names and Functions
⑤ ②
⑰
③④
② POWER ON/STAND-BY button
 Turntheprojectoronoroff.(pp.22-23)
⑥ VIDEO button
 SelecttheVIDEOinputsource.(p.40)
⑦ COMPUTER button
 SelecttheCOMPUTERinputsource.(pp.30-31,41)
⑭ PAGE ▲▼ buttons
Scrollbackandforththepagesonthescreenwhengivingapresentation.Touse
thesebuttons,connecttheprojectorandyourcomputerwithaUSBcable.(pp.11,
19)
⑧ AUTO PC button
 Automaticallyadjustthecomputerimagetoitsoptimumsetting.(pp.28,33,47)
⑯ D.ZOOM ▲▼ buttons
 Zoominandouttheimages.(pp.28,39)
⑪ MENU button
 OpenorclosetheOn-ScreenMenu.(p.24)
⑰ RESET/ON/ALL-OFF switch
When usingthe remotecontrol, set thisswitch to“ON.” Setitto“ALL OFF”for
power saving whenit is notused. Slide thisswitchto "RESET" toinitialize the
remotecontrolcodeorswitchSpotlightandPointertotheLaserpointerfunction.
(pp.14-15)
⑱ IMAGE button
 Selecttheimagemode.(pp.29,36,43)
⑲
MUTE button
 Mutethesound.(p.27)
⑨
KEYSTONE button
 Correctkeystonedistortion.(pp.26,48)
⑩ Point▲▼◄►(VOLUME
+/–
)
buttons
 –SelectanitemoradjustthevalueintheOn-ScreenMenu.(p.24)
 –PantheimageintheDigitalzoom+mode.(p.39)
 –Adjustthevolumelevel.(Point
◄►buttons)(p.27)
㉑
NO SHOW button
 Temporarilyturnofftheimageonthescreen.(p.29)
⑬ LASER button
–OperatetheLaserpointerfunction.Laserbeamisemittedwhilepressingthis
buttonwithin1minute.Whenusingthislaserpointerformorethan1minute,
releasetheLASERbuttonandpressitagain.(p.14)
–DisplaythePointeronthescreen.(p.14)
① L-CLICK button
Actastheleftmousebuttonforwirelessmouseoperation.(p.15)
④ SIGNAL EMISSION indicator
Lightsredwhilethelaserbeamisbeingemittedfromthelaserlightwindowora
signalisbeingsentfromtheremotecontroltotheprojector.
⑫ FREEZE button
 Freezethepictureonthescreen.(p.28)
⑮ LAMP CONTROL button
 Selectalampmode.(pp.28,53)
⑳
P-TIMER button
 OperatetheP-timerfunction.(p.29)
㉒ R-CLICK button
 Actastherightmousebuttonforwirelessmouseoperation.(p.15)
㉓ SELECT button
 –Executetheselecteditem.(p.24)
– ExpandorcompresstheimageinDigitalzoommode.(p.39)
㉔ PRESENTATION POINTER button
Moveapointeroftheprojectororapointerforwirelessmouseoperation.(pp.14-15)
③ WIRED REMOTE jack
Connecttheremotecontrolcable(notsupplied)tothisjackwhenusingasawired
remote control.Wirelessremotecontroldoesnotworkwhenthe remote control
cableisconnectedtotheprojector
㉕ AUTO SET/CANCEL button
–CorrectverticalkeystonedistortionandadjustthePCdisplayparameters.(pp.26,
47)
–DisplaytheimageinSDcardorreturntothemenubarinMemoryViewermenu.
Refertotheowner'smanualof"NetworkSet-upandOperation".
⑤ LASER LIGHT window
 Alaserbeamisemittedfromhere(p.14).
