Installation
Connecting to Component Video Equipment
ExternalAudioEquipment
COMPUTER/COMPONENT
AUDIOIN
Audiocable
(stereo)
Audiocable
(stereo)
AudioInput
ComponentVideoOutput
(Y,Pb/Cb,Pr/Cr)
RGBScart21-
pinOutput
AudioOutput
Component
cable
COMPUTERIN2/COMPONENTIN
Notes:
 •When theAUDIO OUT is plugged-in, the projector's
built-inspeakerisnotavailable.
 •Seepage73fororderingoptionalcables.
•RGBScartsignalcannotbeoutputfromtheMONITOR
OUTterminal.
Unplug the power cords of
both the projector and external
equipment from the AC outlet
beforeconnectingcables.
SD
KB3AC
AUDIO OUT
(stereo)
Scart-VGA
cable
Component-
VGAcable
Cables used for connection
•AudioCables
•Scart-VGACable   
•ComponentCable
•Component-VGACable
(Cablesarenotsuppliedwiththisprojector.)
