Safety Instructions
Usetheprojectorproperlyinspecifiedpositions.Improperpositioningmayreducethelamplifeandresultinsevere
accidentorfirehazard.
Thisprojectorcanprojectthepictureupward,downward,orbackward,perpendiculartotheplaneofthescreenas
showninthefigurebelow.
Bottom
Downward
(Usual)
Front
Downward
Bottom
Upward
Front
Upward
Installing the Projector in Proper Directions
Avoidpositioningtheprojectorasdescribedbelowwheninstalling.
Positioning Precautions
Donotrolltheprojectormorethan10degreesfromsidetoside.
Donotputtheprojectoroneithersidetoprojectanimage.
10˚
10˚
10˚ 10
˚
10˚
10
˚
Inupwardprojection,donottilttheprojectorover10degreesrightandleft.
Indownwardprojection,donottilttheprojectorover10degreesrightandleft.
0º
180º
0º
180º
-50º
NG
GOOD
+50º
40º
50º50º
40º
BesuretosettheLampcontrolinHighandtheFancontrolinOn3inthe
settingmenuwhenusingtheprojectorinclinedatbetween+40degrees
to+140degreestothehorizontalplaneataltitudesbetween0and
approximately1,600metersabovesealevel.
BesuretosettheFancontrolinOn2whenusingtheprojectorathigher
altitudesthanthealtitudesdescribedabove,regardlessoftheinstallation
positionoftheprojector.(p.56).
