Siemens SIMODRIVE POSMO A User Manual

5
5.5 SIMODRIVE POSMO A functions
5-182
 Siemens AG 2013 All Rights Reserved
SIMODRIVE POSMO A User Manual (POS1) – 08/2013 Edition
5.5.10 Digital I/O
For SIMODRIVE POSMO A, there are 2 freely–parameterizable input/
output terminals. The function of a terminal is defined by appropriately
parameterizing it.
 Designation of the input/output terminals (refer to Chapter 2.3.1)
– X5 terminal I/Q1 Terminal 1
– X5 terminal I/Q2 Terminal 2
 Parameterization of the input/output terminals (refer to Chapter 5.6.2)
– P31 Function, terminal 1
– P32 Function, terminal 2
Note
The digital inputs/outputs are updated every 10 ms.
Reader’s note
List of function numbers for digital inputs/outputs?
––> refer to Chapter 5.6.2 under P31 (function, terminal 1)
The list is valid for terminals 1 and 2.
Description
5 Description of the Functions
02.9904.01
