3.3 Commissioning an axis
3-88
E Siemens AG 2013 All Rights Reserved
SIMODRIVE POSMO A User Manual (POS1) – 08/2013 Edition
3.3 Commissioning an axis
The appropriate parameters must be appropriately set to adapt the axis.
The most important parameters for general settings are:
S P1 Axis type
S P2 Travel per gearbox revolution
S P3 Gearbox ratio
S P4 Dimension unit
S P8 Maximum speed
S P10 Maximum velocity
S P22 Maximum acceleration
The most important parameters for monitoring functions are:
S P6 Software limit switch, start
S P7 Software limit switch, end
S P12 Maximum following error
S P14 Standstill range
Note
There are neither software switches nor traversing range limits in the
n–set mode (from SW 2.0).
The drive must always be able to rotate endlessly and therefore to be
parameterized as rotary axis. It must be de–referenced.
Parameters for
general settings
(refer to
Chapter 5.6.2)
Parameters for
monitoring
(refer to
Chapter 5.6.2)
3 Commissioning
02.9905.03
