Siemens SIMODRIVE POSMO A User Manual

C
C.2 Dimension drawings for SIMODRIVE POSMO A – 300W
C-275
E Siemens AG 2013 All Rights Reserved
SIMODRIVE POSMO A User Manual (POS1) – 08/2013 Edition
C.2 Dimension drawings for SIMODRIVE POSMO A – 300W
The dimension drawings for the SIMODRIVE POSMO A – 300W posi-
tioning motor with the following gearboxes are provided in this chapter:
S Motor without gearbox ––> refer to Fig. C-4
S Motor with planet. gearb. (1–stage, 2–stage) ––> refer to Fig. C-5
S Motor with planetary gearbox (3–stage) ––> refer to Fig. C-6
S SIMODRIVE POSMO A – 300 W extension set ”separate version”
– Motor without gearbox ––> refer to Fig. C-7
– Motor with planet. gearb. (1–stage, 2–stage) ––> refer to Fig. C-8
– Motor with planetary gearbox (3–stage) ––> refer to Fig. C-9
Contents
C Dimension Drawings
02.9908.0308.0406.05
