Siemens SIMOREG DC Master 6RA7018-6DS22 User Manual

Connections 02.00
6-44 Siemens AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
6.5 Field supply
Converter type D . . . / 15 to 30
V7
G1G2
K
A
3U1
C98043-A7010
3W1
V8
K
A
3D 3C
AK
AKAK
R1 R2
R1
R2
A7010-L1 3A15A 0R1 0R1
A7010-L2 5A30A 0R1 0R05
XF1-1
XF1-2
XF2-1 XF2-2
Module Rated DC
current fied
Rated DC
current armature
Gating leads are Betatherm 145 1mm²
