02.00 Description
Siemens AG 6RX1700-0AD76 3-23
SIMOREG DC Master Operating Instructions
3.4.18 Converters 3AC 575V, 60A to 600A, 4Q
Order No. 6RA70 . . – 6GV62
25 31 75 81 85
Rated supply voltage armature
1)
V 3AC 575 (+10% / – 20%)
Rated input current armature
2)
A 50 104 175 332 498
Rated supply voltage electronics
power supply
V 2AC 380 (– 25%) to 460 (+15%); I
n
=1A oder
1AC 190 (– 25%) to 230 (+15%); I
n
=2A
(– 35% for 1min)
Rated supply voltage fan V DC24V
internal
3AC 400 (±15%) 50Hz
3AC 460 (±10%) 60Hz
Fan rated current A 0,24
Air flow rate m
3
/h 100 570
Fan noise level dBA 40 73
Rated supply voltage field
1)
V 2AC 460 (+10% / – 20%)
Rated frequency Hz 45 to 65
Rated DC voltage
1)
V 600
Rated DC current A 60 125 210 400 600
Overload capability
6)
max. 180% of rated DC current
Rated output kW 36 75 126 240 360
Power loss at rated DC current
(approx.)
W 265 455 730 1550 1955
Rated DC voltage field
1)
V max. 373
Rated DC current field A 10 15 25
Operational ambient temperature °C 0 to 45 at I
rated
3)
self-cooled
0 to 40 at I
rated
3)
forced-cooled
Storage and transport
temperature
°C – 25 to +70
Installation altitude above sea level
≤ 1000 m at rated DC current
4)
Control stability
Q 
0.006% of the rated motor speed, valid for pulse encoder operation and
digital setpoint
Q 
0.1% of the rated motor speed, valid for analog tacho or analog
setpoint
5)
Environmental class DIN IEC 721-3-3 3K3
Degree of protect. DIN 40050
IEC 144
IP00
Dimensions (HxWxD) mm 385x265x283 625x268x318
Weights (approx.) kg 14 16 30
Explanation at end of list of tables
