Connections 02.00
6-48 Siemens AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Converter
Order No.
C / V Branch fuses
Siemens
Qty. Order No. C / V
A / V A / V
6RA7091-6DS22 1200 / 400 6 3NE3338-8 800 / 800
6RA7090-6GS22 1000 / 575 6 3NE3337-8 710 / 900
6RA7088-6KS22 950 / 690 6 3NE3337-8 710 / 900
6RA7088-6LS22 900 / 830 6 3NE3337-8 710 / 900
6RA7093-4DS22 1600 / 400 6 6RY1702-0BA02 1000 / 660
6RA7093-4GS22 1600 / 575 6 6RY1702-0BA02 1000 / 660
6RA7093-4KS22 1500 / 690 6 6RY1702-0BA03 1000 / 1000
6RA7093-4LS22 1500 / 830 6 6RY1702-0BA03 1000 / 1000
6RA7095-4DS22 2000 / 400 6 6RY1702-0BA01 1250 / 660
6RA7095-4GS22 2000 / 575 6 6RY1702-0BA01 1250 / 660
6RA7095-4KS22 2000 / 690 12 6RY1702-0BA04 630 / 1000
6RA7095-4LS22 1900 / 830 12 6RY1702-0BA04 630 / 1000
Branch fuses are included in converter, external semiconductor fuses are not needed.
6.6.2.2.2 Converters 1Q: 460V
Converter
Order No.
C / V Line fuses
3
Siemens
Line fuses
3
Bussmann
Line fuses
3
Bussmann
Order No. C / V Order No. C / V Order No. C / V
A / V A / V A / V A / V
6RA7018-6FS22 30 / 460 3NE1815-0 25 / 690 170M1562 32 / 660 FWH-35B 35 /500
6RA7025-6FS22 60 / 460 3NE1817-0 50 / 690 170M1565 63 / 660 FWH-60B 60 /500
6RA7028-6FS22 90 / 460 3NE1820-0 80 / 690 170M1567 100 / 660 FWH-100B 100 /500
6RA7031-6FS22 125 / 460 3NE1021-0 100 / 690 170M1568 125 / 660 FWH-125B 125 /500
6RA7075-6FS22 210 / 460 3NE3227 250 / 1000 170M3166 250 / 660 FWH-225B 225 /500
6RA7078-6FS22 280 / 460 3NE3231 350 / 1000 170M3167 315 / 660 FWH-275B 275 /500
6RA7082-6FS22 450 / 460 3NE3233 450 / 1000 170M3170 450 / 660 FWH-450B 450 /500
6RA7085-6FS22 600 / 460 3NE3336 630 / 1000 170M4167 700 / 660 FWH-600B 600 /500
6RA7087-6FS22 850 / 460 3NE3338-8 800 / 800 170M5165 900 / 660 FWH-800B 800 /500
FWH-... and FWP-... fuses are not mechanically compatible with the 3NE... or 170M... fuses.
Converter
Order No.
C / V Branch fuses
Siemens
Qty. Order No. C / V
A / V A / V
6RA7091-6FS22 1200 / 460 6 3NE3338-8 800 / 800
Branch fuses are included in converter, external semiconductor fuses are not needed.
