02.00 Start-Up
SIEMENS AG 6RX1700-0AD76 7-17
SIMOREG DC Master Operating Instructions
13
Documentation of setting values
• Read out parameters with SIMOVIS (see Section 15 “SIMOVIS”)
or
• Document parameters
If P052=0, only parameters that are not set to the default setting are displayed on the operator
control panel.
7.6 Manual optimization (if required)
7.6.1 Manual setting of armature resistance R
A
(P110) and armature inductance
L
A
(P111)
• Setting of armature circuit parameters according to motor list
Disadvantage: The data is very inaccurate and/or the actual values deviate significantly.
The feeder resistances are not taken into account in the armature circuit resistance.
Additional smoothing reactors and feeder resistances are not taken into account in the armature
circuit inductance.
• Rough estimation of armature circuit parameters from motor and supply data
Armature circuit resistance P110
(P100) [A] current armature motor Rated 10
(P101) [V] voltage armature motor Rated
[
R
A
∗
=]
The basis for this formula is that 10% of the rated armature voltage drops across armature
circuit resistor R
A
at rated armature current.
Armature circuit inductance P111
(P100) [A] current armature motor Rated
(P071) [V] section power armature of voltage supply converter Rated 1.4
[mH]L
A
∗
=
The basis for this formula is the empirical value: The transition from discontinuous to continuous
current is at approx. 30% of the rated motor armature current.
• Calculation of armature circuit parameters based on current/voltage measurement
− Select current-controlled operation: P084=2
− Set parameter P153=0 (precontrol deactivated)
− The field must be switched off by setting P082=0 and, in the case of excessively high
remanence, the rotor of the DC motor locked so that it cannot rotate.
− Set the overspeed protection threshold P354=5%
− Enter a main setpoint of 0
− If ”ENABLE OPERATION” is applied and the “SWITCH ON” command entered, an armature
current of approximately 0% now flows.
