Siemens SIMOREG DC Master 6RA7018-6DS22 User Manual

Installation 02.00
5-4 Siemens AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
5.1.2 Converters: 60A to 280A, 1Q

350
283 265
230
15
385
3737108
129
1U1
V8 V7
V1+V4
T2 T3
R100
366
10
1D1 1V1 1C1 1W1
X300
XF1 XF2
100
1)
100
1)
V3+V6 V5+V2
for M8
for M6
17.5
271.5
12.5
48.548.5 48.5
1) Minimum clearance for air circulation An adequate cooling air supply must be provided
