02.00 Description
Siemens AG 6RX1700-0AD76 3-5
SIMOREG DC Master Operating Instructions
Load cycles
Tu DC I DC II DC III DC IV
US rating
Tu=45°C
continuous 15min
100%
60sec
150%
15min
100%
120 sec
150%
15min
100%
10sec
200%
15min
100%
60sec
150%
Recommended
SIMOREG DC Master
° C A AAAAAAAA
830V, 1Q
6RA7088-6LS22 40 900 664,0 996,0 642,0 963,0 595,0 1190,0 632,0 948,0
6RA7093-4LS22 40 1500 1150,0 1725,0 1110,0 1665,0 1040,0 2080,0 1100,0 1650,0
6RA7095-4LS22 40 1900 1486,0 2229,0 1420,0 2130,0 1400,0 2800,0 1412,0 2118,0
3.4.1.2 Load cycles for 4Q applications
Load cycles
Tu DC I DC II DC III DC IV
US rating
Tu=45°C
continuous 15min
100%
60sec
150%
15min
100%
120 sec
150%
15min
100%
10sec
200%
15min
100%
60sec
150%
Recommended
SIMOREG DC Master
° C A AAAAAAAA
400V, 4Q
6RA7013-6DV62 45 15 13,8 20,7 13,4 20,1 12,6 25,2 14,0 20,7
6RA7018-6DV62 45 30 25,0 37,5 24,0 36,0 22,4 44,8 25,0 37,5
6RA7025-6DV62 45 60 53,0 79,5 51,0 76,5 47,0 94,0 53,0 79,5
6RA7028-6DV62 45 90 79,0 118,5 76,0 114,0 72,5 145,0 79,0 118,5
6RA7031-6DV62 45 125 107,0 160,5 104,0 156,0 96,0 192,0 107,0 160,5
6RA7075-6DV62 40 210 165,0 247,5 161,0 241,5 137,0 274,0 158,0 237,0
6RA7078-6DV62 40 280 227,0 340,5 218,0 327,0 202 404,0 216,0 324,0
6RA7081-6DV62 40 400 302,0 453,0 294,0 441,0 250,0 500,0 286,0 429,0
6RA7085-6DV62 40 600 470,0 705,0 454,0 681,0 412,0 826,0 450,0 675,0
6RA7087-6DV62 40 850 660,0 990,0 635,0 952,5 580,0 1160,0 628,0 942,0
6RA7091-6DV62 40 1200 885,0 1327,5 858,0 1287,0 772,0 1544,0 850,0 1275,0
6RA7093-4DV62 40 1600 1250,0 1875,0 1210,0 1815,0 1140,0 2280,0 1190,0 1785,0
6RA7095-4DV62 40 2000 1480,0 2220,0 1435,0 2152,0 1332,0 2664,0 1402,0 2103,0
460V, 4Q
6RA7018-6FV62 45 30 25,0 37,5 24,0 36,0 22,4 44,8 15,0 22,5
6RA7025-6FV62 45 60 53,0 79,5 51,0 76,5 47,0 94,0 30,0 45,0
6RA7028-6FV62 45 90 79,0 118,5 76,0 114,0 72,5 145,0 60,0 90,0
6RA7031-6FV62 45 125 107,0 160,5 104,0 156,0 96,0 192,0 100,0 150,0
6RA7075-6FV62 40 210 165,0 247,5 161,0 241,5 137,0 274,0 140,0 210,0
6RA7078-6FV62 40 280 227,0 340,5 218,0 327,0 202,0 404,0 210,0 315,0
6RA7082-6FV62 40 450 320,0 480 311,0 466,5 275,0 550,0 255,0 382,5
6RA7085-6FV62 40 600 470,0 705 454,0 681,0 412,0 826,0 430,0 645,0
6RA7087-6FV62 40 850 660,0 990 635,0 953,0 580,0 1160,0 510,0 765,0
6RA7091-6FV62 40 1200 885,0 1327,5 858,0 1287,0 772,0 1544,0 850,0 1275,0
