Connectors and binectors 02.00
12-22 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
12.2 Binector list
The states of binectors can be displayed via parameters r045 and P046.
Binector Name, description Function
diag., Sheet
Fixed values
B0000
Fixed value 0 G120
B0001
Fixed value 1 G120
Binary inputs, terminals 36 to 43
B0010
Status of terminal 36 G110
B0011
Status of terminal 36, inverted G110
B0012
Status of terminal 37 G110
B0013
Status of terminal 37, inverted G110
B0014
Status of terminal 38 G110
B0015
Status of terminal 38, inverted G110
B0016
Status of terminal 39 G110
B0017
Status of terminal 39, inverted G110
B0018
Status of terminal 40 G111
B0019
Status of terminal 40, inverted G111
B0020
Status of terminal 41 G111
B0021
Status of terminal 41, inverted G111
B0022
Status of terminal 42 G111
B0023
Status of terminal 42, inverted G111
B0024
Status of terminal 43 G111
B0025
Status of terminal 43, inverted G111
B0032
No meaning
B0033
No meaning
B0034
No meaning
B0035
No meaning
Binary inputs, terminals 211 to 214 / motor interface
B0040
Status of terminal 211 / Brush length monitor (binary) (0=fault) G186
B0041
Status of terminal 211, inverted G186
B0042
Status of terminal 212 / Bearing condition monitor (binary) (1=fault) G186
B0043
Status of terminal 212, inverted G186
B0044
Status of terminal 213 / Motor fan monitor (binary) (0=fault) G186
B0045
Status of terminal 213, inverted G186
B0046
Status of terminal 214 / Motor temperature monitor (binary) (0=fault) G186
B0047
Status of terminal 214, inverted G186
Analog inputs
B0050
Analog input, terminal 4: 1 = Open circuit (i ≤ 2 mA)
G113
B0051
Analog input, terminal 6: 1 = Open circuit (i ≤ 2 mA)
G113
Pulse encoder evaluation
B0052
Fault in digital speed sensing circuit G145
Status word 1
B0100
Stat.word 1, bit 0: 0=not ready to switch on, 1=ready to switch on G182
