02.00 Installation
Siemens AG 6RX1700-0AD76 5-3
SIMOREG DC Master Operating Instructions
5.1 Dimension diagrams for standard devices
5.1.1 Converters: 30A, 1Q
10
10101010

1W11V1
1U1
1D1 1C1
15
385
350
366
70
239
227
60
265 230
V8
V7
V5+V2V1+V4 V3+V6
T2 T3
X300
XF1 XF2
100
1)
100
1)
for M6
17.5
112.5
12.5
63.5
1) Minimum clearance for air circulation An adequate cooling air supply must be provided
