Function descriptions 02.00
9-12 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
9.4.3 Control signals for ramp-function generator
The ramp-function generator operating mode can be preset by the following control signals:
Ramp-function generator start (control word 1.bit 5):
1 = Setpoint is injected at ramp-function generator input
0 = Ramp-function generator is stopped at current value (generator output is injected as generator
input).
Enable setpoint (control word 1.bit 6):
1 = Setpoint enabled at ramp-function generator input
0 = Ramp-function generator setting 1 is activated and 0 applied at the input (generator output is
reduced to 0)
Set ramp-function generator:
1 = The ramp-function generator output is set to the setting value (selected in P639)
Enable ramp-function generator (control word 1.bit 4):
0 = Ramp generator disabled, generator output is set to 0
1 = Ramp-function generator enabled
Ramp-up integrator operation (parameter P302):
See below and Section 11, Parameter List, parameter P302
Enable switchover of ramp-up integrator (select via P646):
See below
Ramp-function generator settings 2 and 3
See below
Ramp-function generator tracking ON (parameter P317):
See below and Section 11, Parameter List, parameter P317
Set ramp-function generator on shutdown (parameter P318):
See Section 11, Parameter List, parameter P318
Bypass ramp-function generator:
1 = Ramp-function generator operates with ramp-up/ramp-down time of 0
The function is controlled via the binector selected in P641.
The ramp generator can also be bypassed in INCHING, CRAWLING and INJECTION OF FIXED
SETPOINT modes.
9.4.4 Ramp-function generator settings 1, 2 and 3
Selection via binectors selected in parameters P637 and P638
Status of binector Effective Effective Effective Effective
Selected via parameter R-F generator ramp-up ramp- lower upper
P637 P638 setting time down time rounding rounding
0 0 1 P303 P304 P305 P306
1 0 2 P307 P308 P309 P310
0 1 3 P311 P312 P313 P314
1 1 Not permitted, activates fault message F041 (selection not clear)
The ramp-function generator settings preset via the binectors selected in P637 and P638 have priority
over the generator setting specified via the ramp-up integrator.
