02.00 Start-Up
SIEMENS AG 6RX1700-0AD76 7-19
SIMOREG DC Master Operating Instructions
7.7 Starting up optional supplementary boards
For information about installing boards, please see Section 5.2.2, Installation of optional
supplementary boards.
The basic converter automatically detects all installed supplementary boards during power-up.
All communications-related settings must be made by means of parameters. The function diagrams
in Section 8 show a general overview of the parameters provided for this purpose.
If two boards of the same type (e.g. two EB1s) are installed in a converter, the slots in which they
are installed determine the parameter settings. The board in the slot with the lower slot letter is the
1
st
board (e.g. the 1
st
EB1) of this particular type and the board with the higher letter the 2
nd
board
(e.g. 2
nd
EB1).
The 1
st
board is parameterized via index 1 and the 2
nd
board via index 2 of the corresponding
parameter.
7.7.1 Procedure for starting up technology boards (T100, T300, T400):
NOTE
Freely configurable technology boards T300 and T400 are guaranteed to operate correctly (board
runup and data exchange with the SIMOREG 6RA70). The user, however, must bear
responsibility for ensuring that the system is properly configured.
1 Disconnect the power supply and insert the board in location 2.
2 Power up the system again to gain access to the parameters of the technology board (d and
H parameters, in some cases also c and L parameters).
The process data are interconnected at the basic converter end by means of the appropriate
connectors and binectors (see Section 8, function diagram Z110)
For meaning of bits of control and status words, please see Section 8, Sheets G180 to G183.
If a communication board is used in addition to a technology board, then data are exchanged
with the basic converter via the technology board. The basic converter cannot directly access
the data of the communication board. The connections of the transfer data are then
determined by the configuration or parameter settings of the technology board.
If a technology board is mounted in location 2, then only one communication board (CBP,
CBC, ...) may be installed in slot G. Other boards are not supported.
