Connections 02.00
6-50 Siemens AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
6.6.2.2.4 Converters 4Q: 460V
Converter
Order No.
C / V Line fuses
3
Siemens
Line fuses
3
Bussmann
Line fuses
3
Bussmann
Order No. C / V Order No. C / V Order No. C / V
A / V A / V A / V A / V
6RA7018-6FV62 30 / 460 3NE1815-0 25 / 690 170M1562 32 / 660 FWH-35B 35 /500
6RA7025-6FV62 60 / 460 3NE1817-0 50 / 690 170M1565 63 / 660 FWH-60B 60 /500
6RA7028-6FV62 90 / 460 3NE1820-0 80 / 690 170M1567 100 / 660 FWH-100B 100 /500
6RA7031-6FV62 125 / 460 3NE1021-0 100 / 690 170M1568 125 / 660 FWH-125B 125 /500
6RA7075-6FV62 210 / 460 3NE3227 250 / 1000 170M3166 250 / 660 FWH-225B 225 /500
6RA7078-6FV62 280 / 460 3NE3231 350 / 1000 170M3167 315 / 660 FWH-275B 275 /500
6RA7082-6FV62 450 / 460 3NE3233 450 / 1000 170M3170 450 / 660 FWH-450B 450 /500
6RA7085-6FV62 600 / 460 3NE3336 630 / 1000 170M4167 700 / 660 FWH-600B 600 /500
6RA7087-6FV62 850 / 460 3NE3338-8 800 / 800 170M5165 900 / 660 FWH-800B 800 /500
Converter
Order No.
C / V DC fuse
1
Siemens
DC fuse
1
Bussmann
Order No. C / V Order No. C / V
A / V A / V A / V
6RA7018-6FV62 30 / 460 3NE4102 40 / 1000 FWP-35B 35 / 660
6RA7025-6FV62 60 / 460 3NE4120 80 / 1000 FWP-70B 70 / 660
6RA7028-6FV62 90 / 460 3NE4122 125 / 1000 FWP-125A 125 / 660
6RA7031-6FV62 125 / 460 3NE4124 160 / 1000 FWP-150A 150 / 660
6RA7075-6FV62 210 / 460 3NE3227 250 / 1000 FWP-250A 250 / 660
6RA7078-6FV62 280 / 460 3NE3231 350 / 1000 FWP-350A 350 / 660
6RA7082-6FV62 450 / 460 3NE3334-OB 500 / 1000 FWP-500A 500 / 660
6RA7085-6FV62 600 / 460 3NE3336 630 / 1000 FWP-700A 700 / 660
6RA7087-6FV62 850 / 460 3NE3334-OB
1)
500 / 1000 FWP-1000A 1000 / 660
FWH-... and FWP-... fuses are not mechanically compatible with the 3NE... or 170M... fuses.
1) Two fuses connected in parallel
Converter
Order No.
C / V Branch fuses
Siemens
Qty. Order No. C / V
A / V A / V
6RA7091-6FV62 1200 / 460 6 3NE3338-8 800 / 800
Branch fuses are included in converter, external semiconductor fuses are not needed.
6.6.2.3 F1 and F2 fuses in the power interface
Only UL listed or UL recognized fuses must be used for UL listed converters.
Wickmann 198 1A / 250 V 5 x 20 mm time lag
Wickmann 343 1A / 250 V 6,3 x 32 mm time lag
Schurter FSD 1A / 250 V 5 x 20 mm time lag Ordering Code 0034.3987
Schurter FST 1A / 250 V 5 x 20 mm time lag Ordering Code 0034.3117
Schurter FSU 1A / 250 V 5 x 20 mm time lag Ordering Code 2010.0017
