02.00 Type spectrum
Siemens AG 6RX1700-0AD76 2-5
SIMOREG DC Master Operating Instructions
2.2 Ordering information for options using codes
SIMOREG converter order no. with suffix Z
and
codes (several codes together) and/or
plaintext (if required)
Options Codes Order No.
Technology software in the basic converter ("Free function
blocks")
S00 6RX1700-0AS00
Module terminal expansion (CUD2) K01 6RX1700-0AK01
SIMOVIS PC - PMU (RS232) connecting cable, 3m 6SX7005-0AB00
SU1 RS232 - RS485 iInterface converter, including mounting
accessories, main connection: 1CA 115V / 230V
- 6SX7005-0AA00
User-friendly operator control panel (OP1S) 6SE7090-0XX84-2FK0
AOP1 adapter for mounting OP1A in cubicle door, including
5 m connecting cable
6SX7010-0AA00
PMU-OP1S connecting cable, 3m 6SX7010-0AB03
PMU-OP1S connecting cable, 5m - 6SX7010-0AB05
LBA Local bus adapter for the electronics box
LBA is always needed to install supplementary boards
(see Section 5.2.2)
6SE7090-0XX84-4HA0
ADB Adapter board
ADB is always needed to install CBC, CBP, EB1, EB2,
SBP and SLB boards
6SE7090-0XX84-0KA0
SBP Pulse encoder evaluation board
1) 2)
3)
(miniature-format board; ADB required)
6SX7010-0FA00
EB1 Terminal expansion board
3)
(miniature-format board; ADB required)
6SE7090-0XX84-0KB0
EB2 Terminal expansion board
3)
(miniature-format board; ADB required)
6SE7090-0XX84-0KC0
SLB SIMOLINK board
1) 3)
(miniature-format board; ADB required)
6SX7010-0FJ00
CBP2 Communications board with interface for SINEC- L2-
DP, (PROFIBUS)
1) 3)
(miniature-format board; ADB required)
6SX7010-0FF05
CBC Communications board with interface for CAN protocol
1) 3)
(miniature-format board; ADB required)
6SX7010-0FG00
CB1 Communications board with interface for SINEC- L2-DP
(PROFIBUS)
3)
The replacement CBP board should be used for new
applications
Operating instructions (german and english)
6SE7090-0XX84-0AK0
6SE7087-6CX84-0AK0
6RA7 00 Z
