Siemens SIMOTION D4x5-2 User Manual

2.4 Commissioning software
Requirement
To
create and edit projects on your PG/PC, you need the SIMOTION SCOUT commissioning
and configuration tool. For information on how to install SIMOTION SCOUT, see the
SIMOTION SCOUT Configuration Manual.
Note
SIMOTION SCOUT contains the functionality of STARTER and SIMATIC S7-Technology.
Simultaneous operation of SIMOTION SCOUT, STARTER, and SIMATIC S7-Technology as
a single installation on one PC/PG is not possible.
Integrated STARTER
You can insert a standalone drive (e.g. SINAMICS S120) with the "Insert single drive unit"
element in the project navigator. It is commissioned using wizards in the working area of the
workbench that contains the STARTER functionality.
SINAMICS Support Package (SSP)
The following SSPs are relevant for SIMOTION SCOUT:
●
SSP "SINAMICS" for single drive units (e.g. CU3xx)
● "SIMOTION SINAMICS Integrated" SSP for the SINAMICS drives integrated into
SIMOTION D.
You will find detailed information on the SSPs in the readme files and in the software
compatibility list at Internet address (
https://support.industry.siemens.com/cs/ww/en/view/
18857317).
Upgrading SIMOTION D4x5‑2 projects and hardware
Projects that you have created for one SIMOTION D4x5‑2 firmware version can also be
converted for other firmware versions. You can also change the version of the
SIMOTION
D4x5‑2. For example, a D445‑2 DP/PN can be converted to a D455‑2 DP/PN (and
vice versa, to the extent that the performance and quantities allow this). See, for example,
Section Adapting a project (Upgrading the project / Replacing the SIMOTION controller)
(Page 347).
SIMOTION IT web server
The SIMOTION D4x5-2 features an integrated Web server.
The web server supports the display of diagnostics and system data in standard Internet
browsers, even in the absence of an engineering system, and the carrying out of project/
firmware updates.
Description
2.4 Commissioning software
SIMOTION D4x5-2
32 Commissioning and Hardware Installation Manual, 03/2018, A5E33441636B

Siemens SIMOTION D4x5-2 Specifications

General

Power Supply	24 V DC
Control Unit Type	SIMOTION D4x5-2
Product type designation	SIMOTION D4x5-2
Communication Interfaces	PROFIBUS, PROFINET, Ethernet
Programming Language	ST (Structured Text), LAD (Ladder Diagram), FBD (Function Block Diagram)
Processor	Intel
Ethernet Ports	Integrated
USB Ports	Integrated
DisplayPort	1
