As well as the maximum number of available performance points, the maximum quantity
structure
of a functionality must also be taken into account (e.g. max. 6 servo drives with 125 µs
current controller cycle clock).
Note
The following method just serves as a rough estimation of the possible quantity structures. It
is not a substitute for dimensioning with the SIZER configuration tool.
Higher utilization can result through the use of SINAMICS function modules (e.g. extended
messages / monitoring functions) or with a DP Integrated cycle clock < 0.5 ms.
Table 7-20
Estimation of the possible quantity structure
Information on dimensioning Your dimensioning (example)
Functionality Characteristic
2)
max. number Performance points Quantity SUM of the perform‐
ance points
Line Module
5)
ALM/SLM with
DRIVE-CLiQ
1 1.3 1 1.3
BLM 1 0.4
Servo
1)
125 μs 6 2 For each
drive
6 12
250 μs 6 1.2 For each
drive
2nd encoder Not relevant 6 2 encoder/
drive
0.1
DO encoder 1 ms 19 0.4 For each DO
Vector
1)
250 μs 3 4 For each
drive
500 μs 6 2 For each
drive
V
/
f
500 μs 12 1 For each
drive
Safety Extended/
Advanced
Function
12 ms Depending on
the drive
0.25 For each
drive
6 1.5
TB30 Not relevant 1 0.1
TM15 DI/DO 250 μs
1 ms
4 ms
8
3)
0.5
0.2
0.1
For each TM
TM31 250 μs
1 ms
4 ms
8
3)
0.5
0.25
0.2
For each TM
TM41
(SIMOTION oper‐
ating mode)
125 μs / 2 ms
4)
125 μs / 4 ms
4)
250 μs / 4 ms
4)
8
3)
1
1
0.5
For each TM
TM54F --- 1
3)
0.5 For each TM
TM15/TM17 Not relevant 8
3)
1 For each TM
CX32-2 Not relevant 6 0.3 For each
CX32-2
Commissioning (software)
7.21 Quantity structures
SIMOTION D4x5-2
328 Commissioning and Hardware Installation Manual, 03/2018, A5E33441636B
