A detailed, regularly updated list of the DRIVE-CLiQ components approved for use with
SIMOTION, as well as notes on their use, can be found on the Internet at (https://
support.industry.siemens.com/cs/ww/en/view/11886029).
If incorrect components are used, a topology error is signaled
F01360 Topology: Actual topology not permitted.
CX32‑2
The tables below provide an overview of the possible combinations:
Table 7-23
Controller extension combinations
Controller extension Article number Use in D4x5 Use in D4x5-2
CX32 6SL3040-0NA00-0AA0 Possible Not possible
CX32‑2 6AU1432-2AA00-0AA0 Not possible Possible
Only approved combinations can be configured. If physically an incorrect controller extension
is used, a topology error is signaled.
F01360 Topology: Actual topology not permitted
CBE30‑2
The tables below provide an overview of the possible combinations:
Table 7-24
Communication Board Ethernet combinations
Communication
Board Ethernet
Article number Use in D4x5 Use in D4x5‑2
CBE30 6FC5312-0FA00-0AA0 Possible Not possible
CBE30‑2 6FC5312-0FA00-2AA0 Not possible
● D4x5-2 DP/PN: As of V4.3
●
D4x5-2 DP: Not possible
Only approved combinations can be configured. If physically an incorrect
Communication Board Ethernet is used, the CBE cannot be fully inserted into the option slot.
CF card
A
CF card with D4x5 firmware / drive software cannot run on a D4x5‑2. The same applies for
the reverse situation.
In case of an error, the 6 LED displays (RUN to DP/MPI) flash yellow at 2 Hz.
Licenses
Licenses purchased for SIMOTION D can be used for both the D4x5 and D4x5‑2.
Previously used platform-specific "MultiAxes Package for D445/D445‑1" licenses can also be
used for the D445‑2 DP/PN and D455‑2 DP/PN.
A new license has not been introduced for the D455‑2 DP/PN performance class.
Commissioning (software)
7.22 Migration of SIMOTION D4x5 to SIMOTION D4x5-2
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual, 03/2018, A5E33441636B 335
