Commissioning

8.1 Requirements for commissioning

Requirements

Table 8-1 Requirements

Prerequisite action See ...

Your system with SIMOTION C is installed. ChapterInstalling (Page 82)

Your system with SIMOTION C is wired. ChapterWiring (Page 89)

For networking via PROFIBUS DP

● The PROFIBUS addresses of the bus nodes with which the SIMOTION

C communicates, are set.

● The terminating resistors are switched on (at segment ends).

When networking via the Ethernet, the IP address / subnet mask of the bus

nodes with which the SIMOTION C communicates, are set.

When networking via PROFINET IO, the PROFINET device names of the

bus nodes with which the C240 PN communicates, are set

ChapterNetworking (Page 119)

ChapterConfiguring an Ethernet subnet on the

Ethernet interface (Page 124)

ChapterConfiguring an Ethernet subnet on the

PROFINET interface (C240 PN) (Page 126)

System requirements

Note

The readme file for the software version you are using provides information about the hardware

and software requirements.

Please take note of the information on the current CD for "SIMOTION SCOUT"!

For online operation, a connection must be established between the PG/PC and the

SIMOTION C via PROFIBUS DP, Ethernet or PROFINET (C240 PN), see chapter Overview

of wiring diagram (Page 92).

The programming device must be equipped with a PROFIBUS or Ethernet card.

You need an MMC adapter to write to the micro memory card (SIMOTION Kernel update) on

the PG/PC, see chapter Writing, formatting and erasing the Micro Memory Card (Page 140).

SIMOTION C

Operating Instructions, 11/2016, A5E33441428B 137
