Note
Use of the drive and encoder interfaces as standard outputs and counter inputs is only possible
via their direct I/O address. Symbolic assignment is not available for this application.
4.8 I/O interface
Front connector
Various encoders and actuators can be connected via digital inputs/outputs to the 40-pin front
connector X1 with single-wire connection.
Position of the connector
The following figure shows the position of the front connector.
/DEHOLQJRILQQHUGRRU)URQWFRQQHFWRULQZLULQJSRVLWLRQ
0
/
0
/
5'<
;
Figure 4-13 Position of connector X1
Interfaces
4.8 I/O interface
SIMOTION C
Operating Instructions, 11/2016, A5E33441428B 69
