5.17.2 Reduced acceptance test after expanding the function
A full acceptance test is necessary only after first commissioning. A reduced acceptance test
is sufficient when safety functions are expanded.
Table 5-1 Reduced acceptance test after expanding the function
Measure Acceptance test Documentation
Changing a single limit
(e.g. SLS level).
Check the modified lim‐
it value.
● Supplement function table
● Log modified settings
● Document the changed checksum and time
stamp
1)
● Countersignature
Functional expansion of
the machine (additional
drive).
Check the safety func‐
tions of the new drive.
● Supplement machine overview
● Supplement article number and firmware
version of the drive
● Supplement function table
● Log the settings of the new drive
● Document the changed checksum and time
stamp
1)
● Countersignature
Functional expansion of a
drive (e.g. additional SLS
level or new safety func‐
tion following a firmware
update).
Check the additional
functions.
● Supplement function table
● Log modified settings
● Document the changed checksum and time
stamp
1)
● Countersignature
Transfer of inverter set‐
tings to other identical ma‐
chines by means of series
commissioning.
Check the control and
feedback signal of all
safety functions.
● Supplement machine description
● Log modified settings
● Check the changed checksum and time
stamp
1)
● Check the firmware versions
1)
The inverter changes the following parameters after changing the settings of the safety functions:
- checksum r9781
- time stamp r9782
Reduced acceptance after a component has been replaced and a firmware change
(Page 366)
Commissioning
5.17 Acceptance tests for the safety functions
Safety Integrated - SINAMICS G110M, G120, G120C, G120D and SIMATIC ET 200pro FC-2
Function Manual, 01/2017, FW V4.7 SP6, A5E34261271B AD 211
